Animal Feed Production Machine Poultry Animal Feed Production Line

Animal Feed Production Machine Poultry Animal Feed Production Line
Animal Feed Production Machine Poultry Animal Feed Production Line Animal Feed Production Machine Poultry Animal Feed Production Line

Large Image :  Animal Feed Production Machine Poultry Animal Feed Production Line

Product Details:
Place of Origin: Henan, China
Brand Name: Shenghong
Certification: BV, SGS, ISO9001, CE
Model Number: SZLH508
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD 6999-19999
Packaging Details: 20GP, 40GP, 40HQ
Delivery Time: within 20 days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 50 sets per month
Contact Now
Detailed Product Description
Product Name: Animal Feed Production Machine Poultry Animal Feed Production Line Voltage: 400V/380V/415V/600V
Feature: High Efficiency Low Cost Usage: Animal Feed Pellet Machine
Color: Clients' Requirement Dimension(l*w*h): Actual
Power: 132/160 Kw Capacity: 10-18t/h
Highlight:

poultry feed machine

,

animal feed processing equipment

,

animal feed production line

Animal Feed Production Machine Poultry Animal Feed Production Line



Parameter of animal feed production machine



Model Power(kw) Capacity(t/h) Directions Application
SZLH250 22 0.6-1.0 According to the customer's different materials and the relative output of different particle sizes, the output of large particles is high, and the output of small particles is small. Granular processing of various livestock and poultry feeds, aquatic feeds, grass meal and organic fertilizers, and processing of aquaculture feeds such as complete sets of units.
SZLH320 37 1.0-3.0
SZLH350 55 3.0-5.0
SZLH420 110 8.0-10.0
SZLH508 132 10.0-18.0




Animal Feed Production Machine Poultry Animal Feed Production Line 0

The process of animal feed production machine



1. Storage of raw materials: There are many raw materials and materials in the feed, and various forms of silos must be used. The main raw materials such as corn, high grain and other grain raw materials have good fluidity and are not easy to agglomerate, and are mostly stored in silo, while the auxiliary materials such as bran, soybean meal and other powdery raw materials have poor scattering properties and are easy to agglomerate after being stored for a period of time. The material is discharged and stored in a room-type warehouse.
2. Cleaning of raw materials: Impurities in feed raw materials not only affect the quality of feed products, but also directly affect the feed processing equipment and personal safety. In severe cases, the entire equipment may be damaged, affecting the smooth progress of feed production. Clear. The cleaning equipment of the feed factory is mainly based on screening and magnetic separation equipment. The screening equipment removes large and long debris such as stones, mud blocks, and sacks in the raw materials. The magnetic separation equipment mainly removes iron impurities.
3. Crushing of raw materials: The technological process of feed crushing is determined according to the required particle size, the variety of the same material and other conditions.
4. Batching technology: At present, the commonly used technological processes include manual batching, volumetric batching, batching with one warehouse and one scale, batching with several scales in multiple warehouses, batching with multiple warehouses and one scale, etc.
5. Mixing process: It can be divided into batch mixing and continuous mixing. Batch mixing is to mix various mixed components according to the proportion of the formula, and send them into the "batch mixer" that works periodically Mixing is carried out in batches. This mixing method is more convenient to change the formula, and the mixing between each batch is less. It is a commonly used mixing process at present, and the opening and closing operations are relatively frequent, so automatic program control is mostly used.
6. Granulation process: (1) Ring die granulation: the quenched and tempered materials are firstly removed by the security magnet, and then evenly distributed between the pressing and mixing and pressing dies, so that the materials enter the extrusion area from the pressing area of ​​the feeding area. The nip is continuously extruded and divided by the pressing roller into the die hole to form a columnar feed, which is cut into granular feed by the cutter fixed outside the die as the die rotates.
7. In the cooling process, a large amount of hot pellet feed is produced due to the introduction of high-temperature and high-humidity steam while the material is squeezed during the pelletizing process.
8. Screening: After the feed is processed by the crushing process, some unqualified materials such as powder agglomerates will be produced. Therefore, the crushed pellet feed needs to be screened into products with neat particles and uniform size.
Animal Feed Production Machine Poultry Animal Feed Production Line 1

Tag:

55kw Animal Feed Production Machine,

22kw Animal Feed Production Machine,

4TPH Animal Feed Production Plant
