Product Details:
Payment & Shipping Terms:
|
| Product Name: | Ring Die Feed Pellet Mill Machine Animal Feed Pelleting Machine Price | Capacity: | 1-3 Tons Per Hour |
|---|---|---|---|
| Raw Material: | Animal Feed Powder | Material: | Stainless Steel Or Carbon Steel |
| Voltage: | 380V/415V | Warranty: | 12 Month |
| High Light: | 3 Tons Ring Die Feed Pellet Mill,1 Tons Ring Die Feed Pellet Mill,3 Tons Animal Feed Pelleting Machine |
||
Ring Die Feed Pellet Mill Machine Animal Feed Pelleting Machine Price
Product description of feed pellet mill machine
SZLH480 Feed set adopts manual batching system with 3-4t/h output for mesh feed 2-3t/h output for pellet feed. The raw material should be weighed in advance before feeding into the production line through two different dumping hopper, in which the material need to be grinded should go into the hammer mill through granule inlet in batches, hammer mill use the pre-cleaner as the feeder, the material no need grinding will go into the production through powder inlet after weighed in advance, then mixed in mixer, the material after mixing can go into the FP bins directly to be mesh finished products. It can also go into the pelletizing process to be pelletized, cooled, finally packed by manual weighing. The total power of the feed set is about 131Kw, dimension is : 12x6x11m, matching 0.3T boiler. The feed set use splicing type frame and is characterized by compact design and reasonable structure, and the satisfaction of environment protection requirements, meanwhile it can be directed to customers design.
Parameter of feed pellet mill machine
| Model No. | Main motor power | Capacity (t/h) | Ring die inner diameter (mm) | Feeder power (kw) | Conditioner motor power (kw) | Size (mm) | Weight (kg) |
| SZLH250 | 22kw | 0.6-1 | 250 | 0.75 | 1.1 | 1750×650×1750 | 800 |
| SZLH320 | 37kw | 1-3 | 320 | 0.75 | 2.2 | 1900×1800×1650 | 2000 |
| SZLH350 | 55kw | 3-5 | 350 | 0.75 | 2.2 | 2100×2000×1850 | 2400 |
| SZLH420 | 110kw | 8-10 | 400 | 1.5 | 4 | 2200×2000×2150 | 2900 |
| SZLH508 | 132/160kw | 10-18 | 450 | 1.5 | 4 | 2300×2350×2150 | 3500 |
Pellets diameter: 2mm, 3mm, 4mm, 4.5mm, 5mm, 6mm, 8mm, 10mm
Pellets shaping rate: ≥95%
Pellets stability in water: ≥20Min
Noise: ≤86dB(A) ≤90dB(A)
Roller working temperature: ≤85ºC
Steam working pressure: 0.1-0.4Mpa
Steam temperature: 130-150ºC
Feature:
