Poultry Animal Feed Production Machine 160kw Pellet Making

2) Crushing process---hammer mills

We have many kinds of hammer mills for your choice: water drop hammer mill, multifunctional hammer mill and 9fq hammer mill etc. This process is mainly used to crush to raw materials into powder,hammer mill sieve size can be 2-12mm.

3) Mixing process---feed mixer

The feed mixer we have are single shaft double screw mixer, double shaft paddle mixer, vertical mixer.The process is used to mixed the crushed materials with higher uniformity.

4) Pellet making process---feed pellet mill

We have five models of feed pellet mill for your choice. This process is to press feed pellet.Feed pellet diameter can be control 1-3cm,and pellet diameter can be 1.5-8mm.

5) Pellet cooling process---counterflow cooler

The newly pressed pellets are very high in temperature. This process is to cool the pellets to +3-5℃ of the room temperature,it will suitalbe for feed pellet directly packed in bag storage.

6) Pellet crumbling process----feed crumbler(roller crusher)

This process is mainly to crush the big pellets into small ones. It is mainly used for chicken feed pellet line. It will suitable for chicken baby feed.

7) Sifting process--vibratory sizing sieve and plenary rotary sizing sieve
This process is mainly to sort out the inappropriate pellets and powder and send the standard pellets to next process.

8) Packaging process -----packaging machine

This process is to pack the pellets into bags which is conveninet for storage and transportation. The above are the main machines in the line. There are some auxiliary equipment such as conveyors(bucket elevator, inclined conveyor and belt conveyor), air compressor and boiler. We can customize for you based on your specific requirements,Each bag can be 20-40kg,200-400bag/h.
