Animal Ring Die Feed Pellet Mill Machine Feed Pellet Production Machine
Introduction of animal feed pellet mill machine
The poultry feed pellet mill machine can produce various poultry feed pellets, suitable for most small and medium-sized feed factories, feed pellets can be used in their own farms or sold
This animal feed pellet mill can be used for processing livestock, poultry and aquatic feed pellets, which is specially suitable for big feed factory, breed farms. It has the better raw material versatility, which can be suitable for pelletizing many kinds of raw material, such as corn, broom corn, wheat, beans, oil seed meal and other materials . And also, this manufacturing plant for animal feed has the features of low energy consumption and high production efficiency for larger profits.e can produce various poultry feed pellets, suitable for most small and medium-sized feed factories, feed pellets can be used in their own farms or sold.
Parameter of animal feed pellet mill machine
| Parameter/Model |
SZLH-350 |
SZLH-320 |
SZLH-250 |
| Output(kg/h) |
3000-5000 |
1000-3000 |
600-1000 |
| Power (kw) |
55 |
37 |
22 |
| Revolving Speed of ring die (r/min) |
330 |
306 |
306 |
| Inside diameter of ring die(mm) |
304 |
250 |
250 |
| Pellet diameter(mm) |
Φ1.5,Φ2,Φ2.5,Φ3,Φ3.5,Φ4,Φ5,Φ6,Φ8 |
| Dimension(m) |
1.35*1.3*1.6 |
1.1*1.15*1.25 |
1.1*1.15.1.25 |
| Weight(kg) |
960 |
710 |
625 |
Advantages of animal feed pellet mill machine
1. Gear directly-connecting driving is adopted for high efficiency;
2. Full stainless steel feeder; Variable pitch anti-bridging structure; Imported FC control;
3. LL stainless steel conditioner with axial steam spraying extends the conditioning and cooking time;
4. Main gear and pinion shaft adopt the carbonizing quenching with high accuracy; Smooth driving, low noise and long service life;
5. Gearbox and driving holes' accuracy are guaranteed by specialized casting supplier and NCC;
6. The bearing and oil seal in the main drive are imported, and especially lubrication oil return system is available to ensure reliable bearing lubrication;
7.2 pc quick disassembling type precisely-cast die clamp is adopted to connect the die and quill flange, resulting in convenient and quick disassembling of die;
8. Pellet chamber door and feed chute are fully made of stainless steel with high anti-corrosion ability and long service life;
9. The connection between motor and gearbox adopts new type S-shape spring coupling with more convenient disassembling and assembling and more reliable use.
Our after-sales Service:
1. Highly inspecting equipments in every working procedure, quality comes first;
2. Fast & Safe Delivery;
3. Assisting our clients for foundation construction of equipments;
4. Dispatching engineers to install and debug equipments;
5. Training the first-line operators on site;
6. Regularly visit clients to solve production problems Providing life-long maintenance service
7. Providing technical exchanging.
FAQ:
1. Are you manufacturer or trade company?
We are a professional manufacturer for producing fertilizer process machines and related machine(granulator, crusher, mixer, packing, feeding machines and conveyor belt) etc.
2. How about the delivery time?
It can be shipped immediately for the machine in stock,and 5-7days for the machine out of stock
3. How long is the guarantee?
Warranty for 12 months without artificial and deliberate damage.
4. How should to do if I meet some trouble while using?
The English manual book and video will be provide for showing how to resolve the problems, if necessary, we will dispatch our engineer to your factory.
5. Do you provide the installation service after ordering your machines?
As for the single machine, we provide the users instruction and operation video.
As for the production line,we provide the professional construction drawing, and arrange the engineer guide the user install the machines.Help the user train the skilled workers.
