Product Details:
Payment & Shipping Terms:
|
| Applicable Industries:: | Manufacturing Plant, Farms, Feed Factory | Power: | 55kw |
|---|---|---|---|
| Pellets Diameter: | 2-12mm | Key Selling Points: | High Productivity |
| Steam Temperature: | 130-150ºC | Condition: | New |
| High Light: | Ring Die Animal Food Extruder Machine,ISO9001 Animal Food Extruder Machine,Ring Die Animal feed pellet extruder |
||
Dog/cat/fish/shrimp food extruder machine animal feed extruder
Introduce:
Ring Animal Feed Extruder Machine are mainly suitable for the middle and small scale feed factory pellet feed making, and may use in the mechanization raising chickens, duck, pigs and various poultries farm feed produce. Also can used for aquatic feed making, such as fish, shrimp and so on.
Parameter of animal feed extruder
| Model | SZLH250 | SZLH320 | SZLH350 | SZLH420 | SZLH508 |
| Power(KW) | 22 | 37 | 55 | 110 | 160 |
| Capacity(T/H) | 1 | 2-4 | 5-7 | 8-10 | 15-20 |
| Inner dia(mm) | 250 | 320 | 350 | 420 | 508 |
| Pellet size(mm) | 2-8 | 2-8 | 2-18 | 2-18 | 2-18 |
How to Work:
SZLH Feed Pellet Machine Equipped with conditioner, this pellet machine will steam and soft the material first to kill the bacteria and improve the qualitiy and capacity of final feed pellets.
It has the better raw material versatility, which can be suitable for pelletizing many kinds of raw material, such as corn, broom corn, wheat, beans, oil seed meal and other materials .
Product Feature:
Die and Roller of poultry feed mill have long service life. Main drive adopts high accurate gear drive with higher efficiency, steady running and low noise.
Ring die pellet mill is fitted with deironing and overload protection device and protection on the machine is fully considered during the operation. High precision gear dribing is adopted, resulting in high driving efficiency and stable working.
The imported bearing and oil seal are used for key positions of drive of the machine so that the machine has long service life and low noise.
Ring die pellet mill can be fitted with single-layer, multiple -layer jacket conditioners or double-shaft differential conditioner so as to meet the different requrements of producing high grade livestock and poultry feed and aquafeed.
Advantages:
1. Wide applicable scope: It can process different materials such as corn, maize, grass, grains, molasses, and some other raw materials.
2. Highly efficient one step gear transmission drive ensures maximum utilization ratio of energy.
3. Full stainless steel feeder; Variable-pitch anti-arch structure; Imported frequency converter control.
4. Stainless steel conditioner extends the conditioning and cooking time. Axial steam spraying port, improving feed cooking efficiency.
5. High precision driving main gear and pinion shaft adopt the carbonizing quenching and hard tooth surface grinding technology, resulting in smooth driving, low noise and long service life.
6. Capacity: We can customize the different capacities from 1 ton per hour to 50 ton per hour or even more.
7. After-sale guarantee: One year warranty and all round after sale service
8. Gearbox: with pinion shaft, main gear, main shaft, quill shaft, gearbox body, manual lubrication system and overload protection system.
9. Coupling assembly: with hub-taper lock bores, bushing-taper locks, S-shaped grid cover etc.
10. One set of roller assembly---two roller system.
11. Ring die special design for low bulk density pelleting
12. Door made with one knife assembly.
13. Feed chute: External discharging can be carried out by pulling out the external discharging lever arm of feed chute to prevent feed from entering the pellet chamber for the convenience of trial run and breakdown removal
