1.5TPH Chicken Animal Feed Pellet Machine Hay Feed Pellet Making Machine

Name: 1.5TPH Chicken Animal Feed Pellet Machine Hay Feed Pellet Making Machine
Brand: Shenghong
SKU: SZLH250
Price: 5999 USD
Availability: InStock
Rating: 4.8 (101 reviews)

Large Image : 1.5TPH Chicken Animal Feed Pellet Machine Hay Feed Pellet Making Machine

Product Details:

Place of Origin:	Henan, China
Brand Name:	Shenghong
Certification:	BV, SGS, ISO9001, CE
Model Number:	SZLH250

Payment & Shipping Terms:

Minimum Order Quantity:	1 Piece
Price:	USD 5999-29999
Packaging Details:	20GP, 40GP, 40HQ
Delivery Time:	within 15 days
Payment Terms:	L/C, T/T, Western Union, MoneyGram
Supply Ability:	20 sets per month

Contact Now

Detailed Product Description

Product Name:	Animal Feed Pellet Machine	Raw Material:	Carbon Steel
Dimension:	326011002200mm	Voltage:	380V, 50hz, 3 Phase
Screw Diameter:	155mm	Application:	Animal Feed Pellet Machine
High Light:	1.5TPH Animal Feed Pellet Machine , Hay Animal Feed Pellet Machine , 1.5TPH Hay Feed Pellet Making Machine

Chicken Animal Feed Pellet Making Machine Hay Feed Pellet Machine Price

Product description

1. moderate grinding fineness(screen hole diameter 2-5mm),

2. moderate curing and conditioning requirements (pellet mill equip with two layers conditioners)

3. SZLH420 (pellet mill machine) poultry & livestock feed plant capacity 10tph,

4. finished products with pellet diameter (pellet diameter is around 2.5-6mm).

5. This plant includes one hammer mill of crushing process, one batching & mixing process, one pellet machine for pelletizing processing and one feed bagging machine of packing process.

6. It is equipped with steam boiler.

7. The whole line of the 10TPH SZLH420 poultry & livestock feed plant is compact in design, reasonable in structure, meeting the requirement of environmental protection, and can be customized according to the requirements of customers.

Parameter

Raw materials	corn,wheat bran,fish meal,bone powder,meat,alfafa,grassetc.
Diameter of feed pellet	2/2.5/3/3.5/4/6/8/10mm
Application	feed pellet machine/plant widely be used for home,poultry and livestock farm.
Capacity	1-3T/H,also can customized according to your demand
Process Step	crushing-mixing-pelletizing--cooler&screener--packing
Warranty	1Year(except spare parts)
Certication	CE
Motor	Siemens Brand Motor
Bearing	Brand
Service after sales	Engineer can provide technical support

Model	Main power(kw)	Out-put(t/h)	Power of Conditioner(kw)	Power of screw feeder(kw)	In-side of rind die(mm)
SZLH250	22	0.5-1.5	2.2	0.55	250
SZLH320	37	2-3	2.2	0.75	320
SZLH350	55	3-5	3	0.75	350
SZLH400	75/90	3-10	5.5	1.5	400
SZLH420	90/110	3-14	5.5	1.5	420
SZLH508	110/132/160	6-15	7.5	2.2	508
SZLH558	180/200	10-20	11	2.2	558
SZLH678	220/250	25-30	18.5	3	678

Feature:

The main drive uses high precision gear drive, the output is about 20% higher than the belt drive type.

Selection of imported high-quality bearings, oil seals, to ensure that the machine running efficient, stable, low noise.

Feeder made of stainless steel, by using frequency control motor to ensure that the quality of particles discharged.

Single Conditioner or double conditioners can be choosed, made of stainless steel, to precook raw materials before pelletizing.

The international advanced level of compensation type serpentine spring coupling, with a new structure, compact, safe, low noise, low fault performance.

Ring mold lifting device, gear box gear oil automatic cooling system.

Working principle of feed pellet machine

The main motor drive the ring die mould rotated. the press roller that were placed inside of the roller does not revolution, but will rotate because the friction of the ring die mould and feed powder raw material.

The feed material was spread evenly into the space between the ring die and roller, and was press into the mould hole, formed column shape pellet, the pellet will rotate along with the rotating ring die mould and will be cutted when the length of the column pellet reach to a certain value.

1.5TPH Chicken Animal Feed Pellet Machine Hay Feed Pellet Making Machine 1

Our service

1) We are the professional manufacturer, which has abundant experience of the machine, also we own research and development team.

2) The professional and timely 24 hours after-sale service.

3) The relative manual and video of the machine installation and instruction will be provided for you.

4) ODM&OEM Provided.

5) The engineer is available to install and training for oversea projects.
