8 TPH Poultry Feed Pellet Mill Making Machine 380V Animal Feed Processing

Name: 8 TPH Poultry Feed Pellet Mill Making Machine 380V Animal Feed Processing
Brand: Shenghong
SKU: SZLH320
Price: 3999 USD
Availability: InStock
Rating: 4.8 (141 reviews)

Large Image : 8 TPH Poultry Feed Pellet Mill Making Machine 380V Animal Feed Processing

Product Details:

Place of Origin:	Henan, China
Brand Name:	Shenghong
Certification:	BV, SGS, ISO9001
Model Number:	SZLH320

Payment & Shipping Terms:

Minimum Order Quantity:	1 Piece
Price:	USD 3999-6999
Packaging Details:	Plywood packing, 20GP, 40GP, 40HQ
Delivery Time:	within 15 days
Payment Terms:	L/C, T/T, Western Union, MoneyGram
Supply Ability:	20 sets per month

Contact Now

Detailed Product Description

Product Name:	Feed Pellet Mill Machine	Capacity:	1-3 Tons Per Hour
Raw Material:	Animal Feed Powder	Material:	Stainless Steel Or Carbon Steel
Voltage:	380V/415V	Warranty:	12 Month
High Light:	380V Feed Pellet Mill Making Machine , 8 TPH Poultry Feed Pellet Machines , Poultry Feed Pellet Processing Machines

5-8 TPH Poultry Feed Pellet Making Machine Animal Feed Processing Machines

Product description:

Feed pellet machine is widely used in the field of poultry and livestock feed pellet making. Feed pellet mill is the main machine for producing pellet feed and is applicable to large and medium-scaled feed plant with different outputs of pellet feed.

This machine features of compact structure, fine appearance, high capacity, low power consumption, convenient operation, and reliable performance.

Dies of various hole diameter such asφ2,φ4,φ6,φ8,φ10 are available . Customers can order dies of different hole diameters according to the production needs.

This machine adopts a system of conversion speed-adjustable feeding and is equipped with strong safety magnet, overload protector, outboard discharging mechanism and manual oil pump lubrication system.

Parameter:

Model No.	Main motor power	Capacity (t/h)	Ring die inner diameter (mm)	Feeder power (kw)	Conditioner motor power (kw)	Size (mm)	Weight (kg)
SZLH250	22kw	0.6-1	250	0.75	1.1	1750×650×1750	800
SZLH320	37kw	1-3	320	0.75	2.2	1900×1800×1650	2000
SZLH350	55kw	3-5	350	0.75	2.2	2100×2000×1850	2400
SZLH420	110kw	8-10	400	1.5	4	2200×2000×2150	2900
SZLH508	132/160kw	10-18	450	1.5	4	2300×2350×2150	3500

Pellets diameter: 2mm, 3mm, 4mm, 4.5mm, 5mm, 6mm, 8mm, 10mm
Pellets shaping rate: ≥95%
Pellets stability in water: ≥20Min
Noise: ≤86dB(A) ≤90dB(A)
Roller working temperature: ≤85ºC
Steam working pressure: 0.1-0.4Mpa
Steam temperature: 130-150ºC

Feature:

1.Gear directly-connecting driving is adopted for high efficiency;

2.Full stainless steel feeder; variable pitch anti-bridgng structre; Imported FC control;

3.LL stainless steel conditioner with axial steam spraying extends the conditioning and cooking time;

4.Main gear and pinion shaft adopt the carbonizing quenching with high accuracy; smooth driving, low noise and long service life;

5.Gearbox and driving holes' accuracy are guaranteed by specialized casting supplier and NCC;

6.The bearing and oil seal in the main drive are imported, and especially lubrication oil return system is available to ensure reliable bearing lubrication;

7.2 pc quick disassembling type precisely-cast die clamp is adopted to connect the die and quill flange, resulting in convenient and quick disassembling of die;

8.Pellet chamber door and feed chute are fully made of stainless steel wit high anti-corrosion ability and long service life;

9.The connection between motor and gearbox adopts new type S-shape spring coupling wth more convenient disassembling and assembling and more reliable use.

8 TPH Poultry Feed Pellet Mill Making Machine 380V Animal Feed Processing 0
